50-100-150-200 Kgs per Hour Solid Waste Incinerator Model TS150 PLC 1570Liters Chamber

January 11, 2020 admin Leave a comment medical-waste

Waste Incinerator Model TS150 PLC, Overview


This model is small-scale waste incineration equipment for small waste output.

Construction is dual/double combustion chamber with 02 sets oil burner, batch load
incineration equipment. Waste feed chamber is 1570Liters (1.57m3, TS150 PLC).
Primary & Secondary combustion chambers and smoke filter chamber.
Batch load on the bottom of chamber. Incinerator PLC panel control suit for local operation.


Primary Combustion Chamber:

※Main Feature:

— Double Combustion Chamber
— Double Italy Burner
— Smoke Filter included
–Burning Rate: 50-200kgs per hour optional
–Primary Combustion Chamber: 1.57M3(1570Liters)
— Incinerator Mainbody steel: 8mm thickness
— Paint for outside face: 800°C Rate

—Chamber Material: High Alumina Fire Brick Wall, 1750℃ Rate
— Idea for campsite average or below 600 people

— Chimney: 10 Meters, Stainless steel


Feeding door primary chamber:


Items/Model

TS150(PLC)


Principle

Waste Incineration Treatment

Burn Rate

Average 150 kg/hour

*(50/100/200kgs/hour optional)

Feed Capacity

Average 750kg/feeding

Control Mode

PLC(Programmable Logic Controller Incinerator)

Main Body Steel

8mm thickness

Chamber Material

High Alumina Fire Brick Wall, 1750℃ Rate

Paint for outside face

800°C Rate

Combustion Chamber

1570L

Internal Dimensions

150x100x105cm

Secondary Chamber

750L

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

210/230V 50/60Hz

Power

0.9Kw

Oil Consumption (kg/hour)

Average 20.4-28.0(D.O)

Gas Consumption (m3/hour)

***

Temperature Monitor

Digital Display

Temperature Protection

Yes

Oil Tank

300L

Feed Door

80x60cm

Chimney

10Meter

Chimney Type

Stainless Steel

1st. Chamber Temperature

800℃–-1000℃

2nd. Chamber Temperature

1000℃-1200℃

Residency Time

2.0 Sec.

Gross Weight

8500kg

External Dimensions

300x160x280cm(without chimney)





Waste Incinerators
Medical Waste Incinerator
Pet Animal Cremation
Solid Waste Incinerator

Tel:  +86-25-8461 0201
Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]
Nanjing Clover Medical Technology Co.,Ltd.

legislation the emission limit value for NOx does not apply to plants only incinerating hazardous waste

December 1, 2019 admin Leave a comment medical-waste

Directive  2000/76/EC  of  the  European  Parliament  and  of  the  Council  of  4 December 2000 on the incineration of waste.

Exemptions for NOx may be authorized by the competent authority for existing incineration plants:

―  with a nominal capacity of 6 tonnes per hour, provided that the

permit foresees the daily average values do not exceed 500 mg/m3 and this until 1 January 2008,

―    with a nominal capacity of >6 tonnes per hour but equal or less than 16 tonnes per hour, provided the permit foresees the daily average values do not exceed 400 mg/m3 and this until 1 January 2010,

―    with a nominal capacity of >16 tonnes per hour but <25 tonnes per hour and which do not produce water discharges, provided that the permit foresees the daily average values do not exceed 400 mg/m3 and this until 1January 2008.



Until 1 January 2008, exemptions for dust may be authorized by the competent authority for existing incinerating plants, provided that the permit foresees the daily average values do not exceed 20 mg/m3.



Since, Hydrogen chloride (HCl), Hydrogen fluoride (HF) , Sulphur (S) are not present in feed so, these will not be present in flue gas.

( B )

Half Hourly Avg. Values

Values

Unit





100 % ( A )

97 % ( B)

mg/m3

1

Total dust

30

10

mg/m3



2

Gaseous and vaporous organic substances, expressed as total organic carbon



20



10



mg/m3

3

Hydrogen chloride (HCl)

60

10

mg/m3

4

Hydrogen fluoride (HF)

4

2

mg/m3

5

Sulphur dioxide (SO2)

200

50

mg/m3





6

Nitrogen monoxide (NO) and nitrogen dioxide (NO2), expressed as nitrogen dixoide for existing incineration plants with a nominal capacity exceeding 6 tonnes per hour or new incineration plants





400 ( * )





200 ( * )





mg/m3

WWW.HICLOVER.COM｜Waste Incinerators ｜Auto Roll Air Filters
Nanjing Clover Medical Technology Co.,Ltd.

Tel:  +86-25-8461 0201

Mobile: +86-13813931455(whatsapp/wechat)
Website: www.hiclover.com
Email: [email protected]
Email: [email protected]

Until 1 January 2010, exemptions for NOx may be authorized by the competent authority for existing incineration plants with a nominal capacity between 6 and 16 tonnes per hour, provided the half-hourly average value does not exceed 600 mg/m3 for column A or 400 mg/m3 for column B.



Since Hydrogen chloride (HCl), Hydrogen fluoride (HF) , Sulphur (S) are not present in feed so, these will not be present in flue gas.



( C ) All average values over the sample period of a minimum of 30 minutes and a maximum of 8 hours.


Sr. No.

All average values over the sample period of a minimum of 30 minutes and a maximum of 8 hours

Unit



1

Cadmium and its compounds, expressed as cadmium (Cd)





Total 0.05





Total 0.1

*





Mg / m3



2

Thallium and its compounds, expressed as thallium (Tl)

3

Mercury and its compounds, expressed as mercury (Hg)

0.05

0.1 *

Mg / m3

4

Antimony and its compounds, expressed as antimony (Sb)





















Total 0.5





















0.1 *





















Mg / m3

5

Arsenic and its compounds, expressed as arsenic (As)

6

Lead and its compounds, expressed as lead (Pb)

7

Chromium and its compounds, expressed as chromium (Cr)

8

Cobalt and its compounds, expressed as cobalt (Co)

9

Copper and its compounds, expressed as copper (Cu)

10

Manganese and its compounds, expressed as manganese (Mn)

11

Nickel and its compounds, expressed as nickel (Ni)

12

Vanadium and its compounds, expressed as vanadium (V)

These average values cover also gaseous and the vapour forms of the relevant heavy metal emissions as well as their compounds.



(d)   Average values shall be measured over a sample period of a minimum of 6 hours and a maximum of 8 hours.



The emission limit value refers to the total concentration of dioxins and furans calculated using the concept of toxic equivalence in accordance with Annex I.



Dioxins and furans  = 0,1 ng/m3



(e)   The following emission limit values of carbon monoxide (CO) concentrations shall not be exceeded in the combustion gases (excluding the start-up and shut- down phase):



―  50 milligrams/m3 of combustion gas determined as daily average value;

―   150 milligrams/m3 of combustion gas of at least 95 % of all measurements determined as 10-minute average values or 100 mg/m3 of combustion gas of all measurements determined as half-hourly average values taken in any 24- hour period.



Exemptions may be authorized by the competent authority for incineration plants using fluidized bed technology, provided that the permit foresees an emission limit value for carbon monoxide (CO) of not more than 100 mg/m3 as an hourly average value.
